WECON HMI PI3070ig (W)

General specification

• Operational Software: Linux 4.4.0 QT based
• Processer: Cortex A35 1.2GHz
• Display:
  • Size: 7"(inches)
  • Resolution: 800*480
  • Colour: 16000k colors
  • Backlight: LED
  • Touch panel: High precision 4wire resistive
• Storage:
  • Memory: 128MB
  • Flash: 128MB
  • SD card slot: YES
  • USB port: USB 2.0 Host + USB2.0 client
• RTC(Real-time-clock) and Calendar: YES
• IO ports:
  • COM1: CN1: RS422/RS485  CN2: RS232 CN3: RS485
  • Ethernet: x1
  • Wi-Fi: YES
  • 4G LTE: NA
• Power consumption:
  • Rated power: ,15w
  • power Voltage: 24VDC
  • Input range: 12 -28 VDC
• Encloser:
  • Shell Colour: Gray
  • Overall size(mm): 201.2W*147.2H*39.0D
  • Mounting size(mm): 192.0W*138.0H
  • Net weight: 0.52kg
